Interfaces | 48x SFP28 10GbE/25GbE ports, 8x QSFP28 100GbE ports, Rear CPU/BMC shared Ethernet Management (RJ45) and Serial Console (RJ45) ports, USB (Type A) |
---|
Switching Capacity | 2.0Tbps IO Bandwidth, 32MByte Buffer |
---|
Latency | Less than 500ns port to port (cut-through mode) |
---|
EEE | 802.3az |
---|
Data Center | DCB, TRILL, Virtual Port (VM) Switching, L2 GRE, NVGRE and VXLAN (encap/decap TEP) |
---|
Telemetry | Improved Instrumentation with Transient Capture Buffer, Packet Timestamp and Buffer Statistics |
---|
CPU | Intel Denverton x86 Processor (up to 8-core), 8-32GB ECC DDR4, Configurable M.2 SSD |
---|
Routing Tables | Unified Forwarding Tables, up to 48K MPLS labels, Up to 324K L3 LPM, Up to 18K ACLs |
---|
Content Aware Processing | Layer 2-7 packet classification, FCoE |
